4MeV电子直线探伤加速器主要参数测量

@关秀芬 $中国原子能科学研究院!北京 102413@杨真媛$ 中国原子能科学研究院!北京 102413@史秀珍 $中国原子能科学研究院!北京 102413@刘桂兰$ 中国原子能科学研究院!北京 102413@毕全理 $中国原子能科学研究院!北京 102413@李景云$ 中国原子能科学研究院!北京 102413

THE MEASUREMENT OF MAJOR PARAMETERS OF 4 MeV RAPHYTRON

摘要: <正> 在加速器中心轴线上距靶1m处,放置标准剂量计空腔电离室,此电离室放在160 mm×150 mm×150 mm的标准有机玻璃模体的最大剂量深度处,用标准次级剂量计进行测量。经激光对中后,在不同重复频率下,重复三次,测得最大吸收剂量率为4.11 Gy/min。
- 剂量率 ,
- 剂量场分布 ,
- 能量 ,
- 焦点大小 ,
- 灵敏度
Abstract: The 4 MeV raphytron consists of an X-ray head,a controller,a modulator cabinet,a cooling water cabinet and a motorized positioning system (option). The raphytron 4MeV is capable of producing useful X-ray beams with characteristics usually used in high energy industrial radiography techniques. The major performance of raphytron 4MeV are as follows:Electron beam energy: 4MeV; X-ray dose rete:≥3. 50 Gy/min (on the central axis);X-ray field size: Φ 400 mm(at one meter) X-ray focal spot size: Φ 2 mmaX-ray flatness:>70% of the central axis intensity (at: ±7.5° of the central axis, no X-ray beam filter); X-ray unsymmetry: <±2% (at ±7. 5° of the central axis) Detection range:for steel, thickness of 50—250mm Radiographic quality : equivalently 1—2T level as defined in ASME E142.
