X波段盘荷波导加速结构的模拟计算与实验测试

@尹厚东 $中国科学技术大学国家同步辐射实验室!安徽合肥230029@裴元吉$ 中国科学技术大学国家同步辐射实验室!安徽合肥230029@黄贵荣 $中国科学技术大学国家同步辐射实验室!安徽合肥230029@贾大春$ 中国科学技术大学国家同步辐射实验室!安徽合肥230029

详细信息

Numerical Calculation and Experimental Investigation on X-band Disk-loaded Waveguide Accelerating Structure

摘要: 介绍了X波段盘荷波导行波加速结构研究的部分计算结果。给出了RF频率为 9 37GHz的X波段盘荷波导行波加速结构物理设计参数, 研究了X波段盘荷波导的特征尺寸的微小变化与加速结构基本物理参数的关系。加工出一些模型腔, 利用网络分析仪对其微波参数和测试条件的影响进行了测量分析。
- X波段盘荷波导 ,
- 特征尺寸 ,
- 实验测量
Abstract: Some numerical research results for X band disk loaded waveguide accelerating structure at National Synchrotron Radiation Laboratory are described. A 9.37 GHz X band travelling wave accelerating structures is designed, and dependent relationship between geometrical factors of the structure and RF parameters are studied. Some model cavities are made, and experimental studies are carried out by network analyzer HP8722D. These results provide a beneficial data for design and manufacture of X band travelling wave accelerating structure.
- X band disk loaded waveguide ,
- geometrical dimensions ,
- experimental studies

[1]	姚充国电子直线加速器 [M] 北京 :科学出版社, 1986 4 2.
[2]	CargotakisG. TheX bandKlystronProgramatSLAC[A]. ProcofWorkshopanPulsedRFSourcesforLin earColliders[C]. Japan, kanagawa :KEK, 1996.72.
[3]	MizanoH. X bandRFSystemforSLC[A]. ProceedingsofWorkshopanPulsedRFSourcesforLinearCol liders[C]. Japan, kanagawa :KEK, 1996.19.
[4]	DolbidorGV, AzorskyNI, BalakinVE, etal.Achievementof 10 0MWOutputPowerinaWideApertureVLEPKlystronWithDistributiedSupperessionofParasiticModes[A]. ProceedingsofWorkshopanPulsedRFSourcesforLinearColliders[C]. Japan, Kanagawa :KEK, 1996.10 0.
[5]	LoewGA. LinearColliderSystemsandCosts[A]. Proceedingsofthe 1993ParticleAcceleratorConference[C]. USA, Washington :IEEEServiceCenter,1993.644～ 645.
