ITER Side 校正场线圈端部大圆弧模压成形及回弹分析

文伟; 吴杰峰; 陈文革; 夏世波; 李波

doi:10.7538/yzk.2010.44.07.0836

ITER Side 校正场线圈端部大圆弧模压成形及回弹分析

1.
中国科学院等离子体物理研究所,安徽合肥230031
2.
中国科学院强磁场科学中心,安徽合肥230031

计量
- 文章访问数: 860
- HTML全文浏览量: 0
- PDF下载量: 1042
出版历程
- 收稿日期: 1899-12-31
- 修回日期: 1899-12-31
- 刊出日期: 2010-07-19

Molding and Spring-Back Effect Analysis for Large Arc of ITER Side Correction Coils

1.
Institute of Plasma Physics, Chinese Academy of Sciences, Hefei 230031, China
2.
High Magnetic Field Laboratory, Chinese Academy of Sciences, Hefei 230031, China

摘要

摘要: 利用大型有限元分析软件ANSYS分析了国际热核实验反应堆（ITER） Side 校正场线圈（CC）端部三维大圆弧模压成形及释放模具后导体的回弹效应，研究了不同半径成形时导体内外表面的应力、应变的分布及释放模具后导体的回弹规律。设计了1套模压成形模具，通过修模的方式在该套成形模具上进行了不同半径成形试验，测得了不同成形半径时模压成形后的回弹量值。试验结果验证了所建立的有限元分析模型的正确性。有限元分析和试验结果表明：ITER Side CC端部三维大圆弧可通过模压成形达到所需的大半径要求，为ITER Side CC端部三维大圆弧成形提供了一种可行方案。
- ITER Side 校正场线圈 ,
- 模压成形 ,
- 回弹 ,
- 有限元分析
Abstract: A finite element analysis （FEM） simulation model for large arc of International Thermonuclear Experimental Reactor (ITER) Side correction coils by molding was established. Processes including molding and spring-back effect after being molded were simulated. The distribution of stress, strain on the inner and outer faces of conductor were gained, and the value of spring-back after being molded was obtained. One set of molding equipment was designed and manufactured, and the value of spring-back with molds of different radiuses by using this equipment was obtained. The experimental results show that the FEM simulation model is correct and molding is a feasible method for the manufacturing of ITER Side correction coils.
- ITER Side correction coil ,
- molding ,
- spring-back ,
- finite element analysis

HTML全文

参考文献(7)

[1]	薛新,刘强,阮锋. 基于数值模拟的弧形件板料弯曲回弹补偿研究[J]. 冲压,2007(6):59-61. XUE Xin, LIU Qiang, RUAN Feng. Spring-back compensation study in sheet metal bending of arc shape workpiece based on numerical simulation[J]. Stamping, 2007(6): 59-61(in Chinese).
[2]	吴建军,张贺刚,王俊彪, 等. 型材拉弯的力学与回弹分析[J]. 材料科学与工艺,2004,12（4）：357-359. WU Jianjun, ZHANG Hegang, WANG Junbiao, et al. Mechanical and spring-back analysis for the stretch-bending process of extruded profile[J]. Materials Science and Technology, 2004, 12（4）: 357-359(in Chinese).
[3]	吴建军,张萍,何朝阳. 大直径薄壁弯管回弹的有限元分析[J]. 特种成形,2009(1)：79-81. WU Jianjun, ZHANG Ping, HE Chaoyang. FEM simulation for the bending spring-back of thin-walled and large diameter tube[J]. Special Forming, 2009(1): 79-81(in Chinese).
[4]	古涛,鄂大辛,高小伟, 等. 管材弯曲成形的有限元模拟与实验分析[J]. 特种成形,2006(1)：66-68. GU Tao, E Daxin, GAO Xiaowei, et al. Finite element simulation and experimental analysis of the forming process of pipe-bending[J]. Special Forming, 2006(1): 66-68(in Chinese).
[5]	杜长城,王俊翔,陈杰富, 等. 锅炉弯管缠绕式冷管成形工艺及回弹的数值模拟[J]. 四川大学学报,2008,40（60）:75-79. DU Changcheng, WANG Junxiang, CHEN Jiefu, et al. Numercial simulation for twisting cold bending process and spring-back of boiler pipe[J]. Journal of Sichuan University: Engineering Science Edition, 2008, 40（60）: 75-79(in Chinese).
[6]	LOU H Z,STELSON K A. Three-dimension tube geometry control for rotary draw tube bending part1: Bend angle and overall tube geometry control[J]. Journal of Manufacturing Science and Engineering, 2001, 5（123）: 258-264.
[7]	詹梅,杨合,栗振斌. 管材数控弯曲回弹规律的有限元分析[J]. 材料科学与工艺,2004,12（4）：349-352. ZHAN Mei, YANG He, LI Zhenbin. FEM numerical analysis of spring-back law of NC tube bending[J]. Materials Science and Technology, 2004, 12（4）: 349-352(in Chinese).
