<sup>17</sup>F+p共振态弹性散射实验中PPAC性能测试

¹⁷F+p共振态弹性散射实验中PPAC性能测试

1.
Institute of Modern Physics, Chinese Academy of Sciences, Lanzhou 730000, China
2.
Graduate University of Chinese Academy of Sciences, Beijing 100049, China

摘要: 在兰州放射性次级束流线（RIBLL）上进行的¹⁷F+p共振态弹性散射实验中，用到的位置灵敏平行板雪崩探测器（PPAC）使用延迟线读出法，使得PPAC有着很干净的本底噪声和较好的信噪比。对实验所用的PPAC进行了性能测试，经分析，位置分辨好于1 mm、时间分辨为0.29 ns、探测效率为97%以上，达到了实验要求。
- 位置灵敏平行板雪崩探测器 ,
- 延迟线读出法 ,
- 位置分辨 ,
- 时间分辨 ,
- 探测效率
Abstract: A parallel plate avalanche counter (PPAC) with delay-line readout was designed to be used in the experiment of investigation of resonant properties in ¹⁸Ne via ¹⁷F+p. The position resolution, time resolution, and detection efficiencies of PPAC were researched in detail. The results of analysis show that 1 mm position resolution, 0.29 ns time resolution, and 97% detection efficiencies are achieved.
- parallel plate avalanche counter ,
- delay-line readout ,
- position resolution ,
- time resolution ,
- detection efficiency

[1]	ZHAN Wenlong, GUO Zhongyan, LIU Guanhua, et al. Radiocative ion beam line in Lanzhou[J]. Science in China A, 1999, 4(5): 529-536.
[2]	GUO Zhongyan, ZHAN Wenlong, LIU Guanhua, et al. The separation techniques for secondary beam at RIBLL[J]. Acta Physica Sinica (Overseas Edition), 1999, 8(1): 21-26.
[3]	谢一冈，陈昌，王曼，等. 粒子探测器与数据获取[M]. 北京：科学出版社，2003：64-86.
[4]	郭忠言，詹文龙，肖国青，等. 两种位置灵敏平行板雪崩探测器[J]. 原子能科学技术，2004，38(2):169-173. GUO Zhongyan, ZHAN Wenlong, XIAO Guoqing, et al. Parallel plate avalanche counter and muli-step parallel plate avalanche counter[J]. Atomic Energy Science and Technology, 2004, 38(2): 169-173(in Chinese).
[5]	毛瑞士，郭忠言，肖国青，等. 一种多极平行板雪崩探测器[J]. 核电子学与探测技术，2004，24（2）：151-154. MAO Ruishi, GUO Zhongyan, XIAO Guoqing, et al. Two dimension position sensitive multi-plate PPAC[J]. Nuclear Electronics & Detection Technology, 2004, 24(2): 151-154(in Chinese).
[6]	王猛，郭忠言，詹文龙，等. 一种高性能双维位置灵敏平行板雪崩探测器[J]. 核技术，2003，26(3)：245-248. WANG Meng, GUO Zhongyan, ZHAN Wenlong, et al. A two dimension position sensitive PPAC[J]. Nuclear Techniques, 2003, 26(3): 245-248(in Chinese).
