长脉冲KrF激光驱动高速飞片实验研究
Experiment Study of Long Pulse Laser-Driven Flyer to High Velocity
-
摘要: 利用侧向阴影成像技术开展了激光驱动高速金属飞片实验研究，并介绍了飞片实验系统与条纹相机时空标定结果。实验在辐照激光波长248 nm、脉宽28 ns、能量100 J、功率密度1.8×1012W/cm2的条件下加速带有50 μm烧蚀层的5 μm铝飞片至10 km/s左右。讨论了不同条件下加速过程的区别，分析了冲击波对飞片加速过程的影响，并从铝、钽飞片实验对比中发现激光烧蚀不同材料的能量转化效率是不同的。Abstract: The technology of side-on shadowgraph was developed to study the velocity of metal flyer driven by laser. The system of flyer experiment，the calibration of time and space axis of streak camera were introduced in the paper. With the laser of 248 nm wavelength, 28 ns pulse duration at laser energy of 100 J and laser intensity of 1.8×1012W/cm2, the 5 μm aluminum flyer with 50 μm ablation layer was accelerated to 10 km/s. The difference of accelerated process in different conditions was discussed and the effect of shock wave in flyer accelerated process was also analyzed in the paper. Through the comparison of Al and Ta experiment results, it is revealed that the energy conversion efficiency of laser material interaction is different for different materials.
-
Keywords:
- side-on shadowgraph ,
- streak camera ,
- ablation layer ,
- shock wave ,
- energy conversion efficiency
-
-
[1] 经福谦. 实验物态方程导引[M]. 北京：科学出版社，1999. [2] VEESER L R, SOLEM J C. Studies of laser-driven shock waves in aluminum[J]. Phys Rev Lett, 1978, 40(21): 1391-1394. [3] TRAINOR B J, SHANER J W, AUERBACH J M, et al. Ultra high-pressure laser-driven shock wave experiments in aluminum[J]. Phys Rev Lett, 1979, 42(17): 1154-1157. [4] 高爽，汤秀章，王钊，等. 利用侧向阴影照相技术探测靶的飞行速度[J]. 强激光与粒子束，2008,20（4）：625-628.GAO Shuang, TANG Xiuzhang, WANG Zhao, et al. Detection of flyer velocity by side-on shadowgraph system in equation of state experiment[J]. High Power Laser and Particle Beams, 2008, 20(4): 625-628（in Chinese）. [5] ZVORYKIN V D, LEBO I G. Laser and target experiments on KrF GARPUN laser installation at FIAN[J]. Laser and Particle Beams, 1999, 17(1): 69-88. [6] 彭晓世,刘永刚,张惠鸽,等. 光学条纹相机扫描速度实验标定[J]. 核电子学与探测技术,2008,28(4):841-844.PENG Xiaoshi, LIU Yonggang, ZHANG Huige, et al. Experiment calibration of sweep speed for optic streak camera[J]. Nuclear Electronics & Detection Technology, 2008, 28(4):841-844（in Chinese）. [7] 梁晶，单玉生，汤秀章，等. 烧蚀层厚度对飞片稳定性的影响[J]. 原子能科学技术，2007,41（2）：153-157.LIANG Jing, SHAN Yusheng, TANG Xiuzhang, et al. Effect of stability of flyers by altering thickness of ablators[J]. Atomic Energy Science and Technology, 2007, 41（2）: 153-157（in Chinese）. [8] BATES J W. Instability of isolated planar shock waves[J]. Phys Fluids, 2007, 19(9): 094102. [9] KARASIK M, WEAVER J L, AGLITSKIY Y, et al. Acceleration to high velocities and heating by impact using Nike KrF laser[J]. Phys Plasmas, 2010, 17(5): 056317.
