PET图像中球形病灶的部分容积效应及其影响因素

陈英茂; 耿建华; 田嘉禾; 徐白萱; 姚树林; 邵明哲

doi:10.7538/yzk.2014.48.06.1136

PET图像中球形病灶的部分容积效应及其影响因素

1.
中国人民解放军总医院核医学科,北京100853
2.
中国医学科学院肿瘤医院核医学科,北京100021

计量
- 文章访问数: 327
- HTML全文浏览量: 0
- PDF下载量: 973
出版历程
- 刊出日期: 2014-06-19

Partial Volume Effect and Its Influence Factors for Sphere Lesion PET Images

1.
Department of Nuclear Medicine, Chinese PLA General Hospital, Beijing 100853, China
2.
Department of Nuclear Medicine, Cancer Hospital, cademy of Chinese Medical Science, Beijing 100021, China

摘要

摘要: 依据形成部分容积效应的理论，由计算机模拟球形病灶（直径2～30 mm）位于各种背景（背景与病灶强度之比为0～0.7）中时，PET设备（分辨率3～15 mm）的成像实验。计算模拟图像中病灶的像素最大值、平均值及半高宽，由此探讨球形病灶PET成像的部分容积效应与相关影响因素间的关系，为进一步建立部分容积效应校正方法提供依据。结果表明：对于任一分辨率和背景强度，图像上病灶信号强度的最大值及平均值随病灶直径的增大而呈S形增加；对于任一病灶直径和背景强度，病灶强度的最大值及平均值随分辨率的增大而呈倒S形减小；对于任一病灶直径和分辨率，病灶强度的最大值及平均值随背景强度线性增加，以背景为基点时，高出背景的病灶强度（最大值、平均值）与相应病灶真值之比不随背景强度变化；对任一病灶直径和分辨率，病灶半高宽不随背景强度变化；当病灶直径大于分辨率时，病灶半高宽与其真实直径很接近，但随分辨率变差，其接近程度也变差；当病灶直径小于分辨率时，病灶半高宽基本不再随直径变小而变小，而是基本等于空间分辨率，并保持不变。
- PET ,
- 部分容积效应 ,
- 影响因素 ,
- 模拟实验
Abstract: To investigate the partial volume effect (PVE) and its influence factors for sphere lesion positron emission tomography (PET) images and provide the basis for PVE correction, the computer simulation experiments for PET imaging were performed. According to the theory of PVE formation, PET images of the sphere lesions with diameter of 2.30 mm were simulated with computer program in the ratio of background to lesion of 0-0.7 under system resolution of 3.15 mm. The maximum and the average pixel values and the width of the lesion images were calculated. The results show that the maximum and average pixel values increase with the lesion diameter in S shape under every system resolution and background. The maximum and average pixel values decrease in inverse S shape with the increasing of the system resolution under every lesion diameter and background. The maximum and average pixel values linearly increase with the increasing of background under every lesion diameter and system resolution. The width of the lesion image is independent of the background under every lesion diameter and system resolution. The FWHM of the lesion image is close to the lesion diameter for the lesion which size is larger than system resolution and the difference increases with the system resolution value, it doesn’t change with the lesions which size is smaller than system resolution and it is equal to the system resolution.
- positron emission tomography ,
- partial volume effect ,
- influence factor ,
- simulation experiment

HTML全文

参考文献(23)

[1]	MAISONOBE J A, GARCIA C A, NECIB H, et al. Comparison of PET metabolic indices for the early assessment of tumour response in metastatic colorectal cancer patients treated by polychemotherapy[J]. Eur J Nucl Med Mol Imaging, 2013, 40(2): 166-174.
[2]	COELLO C, WILLOCH F, SELNES P, et al. Correction of partial volume effect in ¹⁸F-FDG PET brain studies using coregistered MR volumes: Voxel based analysis of tracer uptake in the white matter[J]. Neuroimage, 2013, 72(1): 183-192.
[3]	THOMAS B A, ERLANDSSON K, MODAT M, et al. The importance of appropriate partial volume correction for PET quantification in Alzheimer’s disease[J]. Eur J Nucl Med Mol Imaging, 2011, 38(6): 1104-1119.
[4]	GIOVACCHINI G, LERNER A, TOCZEK M T, et al. Brain incorporation of ¹¹C-arachidonic acid, boold volume, and blood flow in healthy aging: A study with partialvolume correction[J]. J Nucl Med, 2004, 45(9): 1471-1479.
[5]	TORIGIAN D A, LOPEZ R F, ALAPATI S, et al. Feasibility and performance of novel software to quantify metabolically active volumes and 3D partial volume corrected SUV and metabolic volumetric products of spinal bone marrow metastases on ¹⁸F-FDG-PET/CT[J]. Hell J Nucl Med, 2011, 14(1): 8-14.
[6]	BENCHERIF B, STUMPF M J, LINKS J M, et al. Application of MRI-based partial-volume correction to the analysis of PET images of u-opioid receptors using statistical parametric mapping[J]. J Nucl Med, 2004, 45(3): 402-408.
[7]	QUARANTELLI M, BERKOUK K, PRINSTER A, et al. Integrated software for the analysis of brain PET/SPECT studies with partial-volume-defect correction[J]. J Nucl Med, 2004, 45(2): 192-201.
[8]	BARBEE D L, FLYNN R T, HOLDEN J E, et al. A method for partial volume correction of PET imaged tumor heterogeneity using expectation maximization with a spatially varying point spread function[J]. Phys Med Biol, 2010, 55(1): 221-236.
[9]	FANG Y H, MUZIC R F, Jr. Spillover and partial-volume correction for image-derived input functions for small-animal 18F-FDG PET studies[J]. J Nucl Med, 2008, 49(4): 606-614.
[10]	SRINIVAS S M, DHURAIRAJ T, BASU S, et al. A recovery coefficient method for partial volume correction of PET images[J]. Ann Nucl Med, 2009, 23(4): 341-348.
[11]	耿建华,陈盛祖,陈英茂,等. 正电子图像部分容积效应成因与校正的理论探讨[J]. 中华核医学杂志,2003,23(5):318-319.GENG Jianhua, CHEN Shengzhu, CHEN Yingmao, et al. Theoretic analysis of the causes and correction of partial volume effect in positron emission tomography imaging[J]. Chin J Nucl Med, 2003, 23(5): 318-319(in Chinese).
[12]	陈英茂,耿建华,田嘉禾,等. 正电子发射断层扫描图像部分容积效应的模拟研究及实验检验[J]. 原子能科学技术,2004,38(5):467-473.CHEN Yingmao, GENG Jianhua, TIAN Jiahe, et al. Simulation study and experiment verify of partial volume effect for positron emission tomography[J]. Atomic Energy Science and Technology, 2004, 38(5): 467-473(in Chinese).
[13]	陈英茂,耿建华,田嘉禾,等. PET显像部分容积效应的实验研究[J]. 中国医学影像技术,2004,20(1):99-102.CHEN Yingmao, GENG Jianhua, TIAN Jiahe, et al. Partial volume effect in PET images: Phantom study[J]. Chin J Med Imaging Technol, 2004, 20(1): 99-102(in Chinese).
[14]	陈英茂,耿建华,田嘉禾,等. PET系统分辨力及影响因素的实验研究[J]. 中国医学影像技术,2004,20(5):778-780.CHEN Yingmao, GENG Jianhua, TIAN Jiahe, et al. Experimental study of system resolution and influence factors in positron emission romography[J]. Chin J Med Imaging Technol, 2004, 20(5): 778-780(in Chinese).
[15]	耿建华,陈英茂,陈盛祖,等. 双探头符合成像系统的分辨率及其影响因素[J]. 核电子学与探测技术,2007,27(2):180-183.GENG Jianhua, CHEN Yingmao, CHEN Shengzhu, et al. Dual-head coincidence imaging resolution and influence factors[J]. Nucl Electro Detect Technol, 2007, 27(2): 180-183(in Chinese).
[16]	耿建华,陈英茂,陈盛祖,等. 双探头符合图像SUV与PET图像SUV的比较研究[J]. 中华核医学杂志,2004,24(5):308-309.GENG Jianhua, CHEN Yingmao, CHEN Shengzhu, et al. Comparison of dual-head coincidence imaging SUV with PET imaging SUV: A phantom study[J]. Chin J Nucl Med, 2004, 24(5): 308-309(in Chinese).
[17]	耿建华,陈盛祖,陈英茂,等. 部分容积效应对双探头符合探测图像的影响[J]. 中华核医学杂志,2003,23(4):247-249.GENG Jianhua, CHEN Shengzhu, CHEN Yingmao, et al. Influence of partial volume effect on fualhead coincidence FDG images[J]. Chin J Nucl Med, 2003, 23(4): 247-249(in Chinese).
[18]	陈英茂,耿建华,田嘉禾,等. 一种简单校正PET图像部分容积效应的方法[J]. 核电子学与探测技术,2007,27(6):1231-1238.CHEN Yingmao, GENG Jianhua, TIAN Jiahe, et al. A simple method for partial volume effect correction in PET images[J]. Nucl Electro Detect Technol, 2007, 27(6): 1231-1238(in Chinese).
[19]	耿建华,陈英茂,田嘉禾,等. 校正PET图像上病灶SUV值的研究[J]. 核电子学与探测技术,2009,29(4):925-930. GENG Jianhua, CHEN Yingmao, TIAN Jiahe, et al. Lesion’s standard uptake value correction in PET images[J]. Nucl Electro Detect Technol, 2009, 29(4): 925-930(in Chinese).
[20]	陈英茂,田嘉禾. 计算机模拟试验与实际实验的区别及优缺点[J]. 中华核医学杂志,2002,22(6)：371.
[21]	GEWORSKI L, KNOOP B O, CABREJAS M L, et al. Recovery correction for quantitation in emission tomography: A feasibility study[J]. Eur J Nucl Med, 2000, 27(2): 161-169.
[22]	MENDA Y, BUSHNELL D L, MADSEN M T, et al. Evaluation of various corrections to the standardized uptake value for diagnosis of pulmonary malignancy[J]. Nucl Med Commun, 2001, 22(10): 1077-1081.
[23]	SAKAGUCHI Y, MIZOGUCHI N, MITSUMOTO T, et al. A simple table lookup method for PET/CT partial volume correction using a point-spread function in diagnosing lymph node metastasis[J]. Ann Nucl Med, 2010, 24(8): 585-591.
