类丁二炔凝胶复合材料的辐射变色性能研究

王潇; 敖银勇; 赵岩; 孙鹏; 黄玮

doi:10.7538/yzk.2016.50.06.0983

类丁二炔凝胶复合材料的辐射变色性能研究

王潇¹,
敖银勇^1,2,
赵岩¹,
孙鹏³,
黄玮^1,*

1.
中国工程物理研究院核物理与化学研究所,四川绵阳621900
2.
北京大学北京分子科学国家实验室,北京100871
3.
四川大学原子核科学技术研究所,四川成都610064

计量
- 文章访问数: 157
- HTML全文浏览量: 0
- PDF下载量: 1097
出版历程
- 刊出日期: 2016-06-19

Study on Radiochromic Property of Diacetylene Gel Composite

1.
Institute of Nuclear Physics and Chemistry, China Academy of Engineering Physics, Mianyang 621900, China
2.
Beijing National Laboratory for Molecular Sciences, Peking University, Beijing 100871, China
3.
Institute of Nuclear Science and Technology, Sichuan University, Chengdu 610064, China

摘要

摘要: 以丙烯酰胺凝胶为载体、类丁二炔（10,12-二十五碳二炔酸）囊泡为显色物质，合成了一种新型辐射变色复合材料，并对其性能进行了系统研究。辐照后复合材料由无色透明变为蓝色，主吸收峰出现在660 nm附近，其吸光度与吸收剂量具有线性关系。辐照前后类丁二炔囊泡的拉曼光谱分析发现，随着吸收剂量的增加，类丁二炔的拉曼位移在2200cm^-1处的共轭三键振动吸收峰逐渐减弱并消失，2100cm^-1处的三键-双键共轭吸收峰增强且向低波数区域移动，表明类丁二炔囊泡单体在辐照过程中发生了聚合反应。剂量率、分次辐照和扩散效应等因素对类丁二炔凝胶复合材料的影响研究结果显示：在2~40 Gy/min的范围内，剂量响应随剂量率的变化较小；分次辐照与单次辐照的结果一致；类丁二炔囊泡在丙烯酰胺凝胶中无明显扩散效应。综上，该复合材料有望用于三维空间的剂量测定，剂量测量范围为100~2000 Gy。
- 类丁二炔 ,
- 辐射变色 ,
- 丙烯酰胺凝胶 ,
- 复合材料 ,
- 三维空间
Abstract: A new type of radiochromic gel composite, which was composed of acrylamide gels as carrier and diacetylene (10, 12-pentacosadiynoic acid) vesicles as chromogenic agent, was prepared, and its radiochromic properties were studied. The color of the gel composites changed from colorless to blue after irradiation. The main absorption peak at around 660 nm appears in the UV-Vis spectroscopy, and its absorbance has a linear relationship with the absorbed dose. For comparison purpose, the diacetylene vesicles were irradiated and analyzed by Raman spectroscopy. The results show that the peak at 2200 cm^-1 in Raman shift corresponding to C≡C—C≡C vibration gradually attenuates and disappears, and the peak at near 2 100 cm^-1 corresponding to C≡C—C=C vibrations moves to a lower wavenumber with the increasing absorbed dose. These results indicate that the diacetylene vesicles are polymerized gradually during irradiation. The dose-rate effect, the fractionated-irradiation effect and the diffusion-effect of the diacetylene gel composites were studied additionally. The dose rate shows negligible influence on dose response in the range of 2.40 Gy/min. The dose response with the fractionated irradiation up to a certain dose is consistent with a single continuous irradiation. There is no obvious diffusion effect in diacetylene vesicles embedded in acrylamide gels. Based on the results above, the diacetylene gel composites are promising to be used in measuring the three-dimensional space dose, and the range of dosage measuring is about 100-2000Gy.
- diacetylene ,
- radiochromic ,
- acrylamide gel ,
- composite ,
- three-dimensional space

HTML全文

参考文献(26)

[1]	阿蒂克斯罗奇. 辐射剂量学[M]. 施学明,陈常茂,于耀明，等译. 北京:原子能出版社,1981.
[2]	SEPHTON J P, SHARPE P H G, CHU R D H. The use of ionisation chambers for dose rate measurements at industrial irradiation plants[J]. Radiation Physics and Chemistry, 2002, 63(3): 789-792.
[3]	FRICKE H, HART E J. Chemical dosimetry[J]. Radiation Dosimetry, 1966(2): 167-239.
[4]	NAKAJIMA T, MURAYAMA Y, MATSUZAWA T, et al. Development of a new highly sensitive LiF thermoluminescence dosimeter and its applications[J]. Nuclear Instruments and Methods, 1978, 157(1): 155-162.
[5]	TAMURA N, TANAKA R, MITOMO S, et al. Properties of cellulose triacetate dose meter[J]. Radiation Physics and Chemistry, 1981, 18(5): 947-956.
[6]	NIROOMAND-RAD A, BLACKWELL C R, COURSEY B M, et al. Radiochromic film dosimetry: Recommendations of AAPM radiation therapy committee task group 55[J]. Medical Physics, 1998, 25(11): 2093-2115.
[7]	DAY M J, STEIN G. Chemical effects of ionizing radiation in some gels[J]. Nature, 1950, 166: 146-147.
[8]	GORE J C, KANG Y S. Measurement of radiation dose distributions by nuclear magnetic resonance (NMR) imaging[J]. Physics in Medicine and Biology, 1984, 29(10): 1189-1196.
[9]	SCHULZ R J, MARYANSKI M J, IBBOTT G S, et al. Assessment of the accuracy of stereotactic radiosurgery using Fricke-infused gels and MRI[J]. Medical Physics, 1993, 20(6): 1731-1734.
[10]	BALDOCK C, HARRIS P J, PIERCY A R, et al. Experimental determination of the diffusion coefficient in two-dimensions in ferrous sulphate gels using the finite element method[J]. Australasian Physics & Engineering Sciences in Medicine, 2001, 24(1): 19-30.
[11]	MARYANSKI M J, SCHULZ R J, IBBOTT G S, et al. Magnetic resonance imaging of radiation dose distributions using a polymer-gel dosimeter[J]. Physics in Medicine and Biology, 1994, 39(9): 1437-1445.
[12]	BALDOCK C, BURFORD R P, BILLINGHAM N, et al. Experimental procedure for the manufacture and calibration of polyacrylamide gel (PAG) for magnetic resonance imaging (MRI) radiation dosimetry[J]. Physics in Medicine and Biology, 1998, 43(3): 695-703.
[13]	FONG P M, KEIL D C, DOES M D, et al. Polymer gels for magnetic resonance imaging of radiation dose distributions at normal room atmosphere[J]. Physics in Medicine and Biology, 2001, 46(12): 3105-3113.
[14]	VENNING A J, BRINDHA S, HILL B, et al. Preliminary study of a normoxic PAG gel dosimeter with tetrakis (hydroxymethyl) phosphonium chloride as an anti-oxidant[J]. Journal of Physics: Conference Series, 2004, 3(1): 155-158.
[15]	BALDOCK C, de DEENE Y, DORAN S, et al. Polymer gel dosimetry[J]. Physics in Medicine and Biology, 2010, 55(5): R1-R63.
[16]	LU S, JIA C, DUAN X, et al. Polydiacetylene vesicles for hydrogen peroxide detection[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2014, 443: 488-491.
[17]	CHANAKUL A, TRAIPHOL N, FAISADCHA K, et al. Dual colorimetric response of polydiacetylene/zinc oxide nanocomposites to low and high pH[J]. Journal of Colloid and Interface Science, 2014, 418: 43-51.
[18]	OKADA S, PENG S, SPEVAK W, et al. Color and chromism of polydiacetylene vesicles[J]. Accounts of Chemical Research, 1998, 31(5): 229-239.
[19]	KIM J M, LEE Y B, CHAE S K, et al. Patterned color and fluorescent images with polydiacetylene supramolecules embedded in poly (vinyl alcohol) films[J]. Advanced Functional Materials, 2006, 16(16): 2103-2109.
[20]	刘强,蒋波,何捷,等. 高感度辐射变色薄膜电子剂量计[J]. 强激光与粒子束,2008,20(12):2072-2076. LIU Qiang, JIANG Bo, HE Jie, et al. A new highly sensitive radiochromic film electronic dosimeter[J]. High Power Laser and Particle Beams, 2008, 20(12): 2072-2076(in Chinese).
[21]	孙鹏,蒋波,何捷,等. 灵敏辐射变色薄膜γ射线辐照研究[J]. 核技术,2009,32(4):273-276.SUN Peng, JIANG Bo, HE Jie, et al. Gamma ray radiation study on sensitive radiochromic films[J]. Nuclear Techniques, 2009, 32(4): 273-276(in Chinese).
[22]	GUO C X, BOULLANGER P, LIU T, et al. Size effect of polydiacetylene vesicles functionalized with glycolipids on their colorimetric detection ability[J]. The Journal of Physical Chemistry B, 2005, 109(40): 18765-18771.
[23]	KEW S J, HALL E A H. pH response of carboxy-terminated colorimetric polydiacetylene vesicles[J]. Analytical Chemistry, 2006, 78(7): 2231-2238.
[24]	MA Z, REN J. Fabrication of stable polydiacetylene vesicles with 2, 4-akyl-diacetylenic acid[J]. Colloids and Surfaces A: Physicochemical and Engineering Aspects, 2007, 303(3): 179-183.
[25]	SETO K, HOSOI Y, FURUKAWA Y. Raman spectra of Langmuir-Blodgett and Langmuir-Schaefer films of polydiacetylene prepared from 10, 12-pentacosadiynoic acid[J]. Chemical Physics Letters, 2007, 444(4): 328-332.
[26]	CHAROENTHAI N, PATTANATORNCHAI T, WACHARASINDHU S, et al. Roles of head group architecture and side chain length on colorimetric response of polydiacetylene vesicles to temperature, ethanol and pH[J]. Journal of Colloid and Interface Science, 2011, 360(2): 565-573.
