钠冷快堆直流式蒸汽发生器固定网格与滑移网格模型对比分析
Analysis of Fixed and Movable Boundary Models for Once-through Steam Generator of Sodium-cooled Fast Reactor
-
摘要: 根据钠冷快堆核电厂直流式蒸汽发生器（OTSG）的热工水力特性，基于固定网格模型和滑移网格模型编制了OTSG瞬态分析程序OTAC。对美国能源技术工程中心(ETEC)的OTSG停闭实验进行了模拟，并将计算值与实验值作了对比分析。结果发现，两种模型的计算值与实验值吻合较好，其中固定网格模型只有在网格数目足够多时才能避免计算结果的突跳，而滑移网格模型可在较少网格数目下取得很好的计算效果，提高了数值稳定性，避免了计算结果的不连续。Abstract: According to the thermal-hydraulic characteristics of once-through steam generator (OTSG) of sodium-cooled fast reactors, the OTSG transient analysis code OTAC was established based on the fixed and movable boundary models. The United States Energy Technology Engineering Center OTSG shutdown experiment was simulated by OTAC, and the calculated and experimental results were compared and analyzed. The calculated values of the two models are in good agreement with the experimental values. The step results can be avoided only in enough grids for the fixed boundary model. However, the numerical stability and the continuous calculation results can be improved based on less number of the grid for the movable boundary model.
-
-
[1] 袁媛，彭敏俊，夏庚磊，等. 螺旋管式直流蒸汽发生器热工水力分析模型[J]. 原子能科学技术，2014，48（增刊）：251-256.YUAN Yuan, PENG Minjun, XIA Genglei, et al. Thermal-hydraulic model for helical-coil once-through steam generator[J]. Atomic Energy Science and Technology, 2014, 48(Suppl.): 251-256(in Chinese). [2] 解衡，张金玲，贾斗南，等. 直管式直流蒸汽发生器的热工水力特性分析与计算[J]. 核科学与工程，1997，17（2）：97-102.XIE Heng, ZHANG Jinling, JIA Dounan, et al. Thermal hydraulic predictions of once-through steam generator[J]. Chinese Journal of Nuclear Science and Engineering, 1997, 17(2): 97-102(in Chinese). [3] 张建民，李京光，桑维良. 钠冷快堆蒸汽发生器的模块化模型及瞬态仿真研究[J]. 核动力工程，1999，20（1）：79-82.ZHANG Jianmin, LI Jingguang, SANG Weiliang. Modular modeling and transient simulation research of once-through steam generator for sodium cooled fast reactor[J]. Nuclear Power Engineering, 1999, 20(1): 79-82(in Chinese). [4] 苏光辉，秋穗正，田文喜，等. 核动力系统热工水力计算方法[M]. 北京：清华大学出版社，2013. [5] 蒸汽发生器编写组. 蒸汽发生器[M]. 北京：原子能出版社，1982. [6] TZANOS C P. A movable boundary model for once-through steam generator analysis[J]. Nuclear Technology, 1988, 82(1): 5-20. [7] 苏著亭，叶长源，阎凤文，等. 钠冷快增殖堆[M]. 北京：原子能出版社，1991. [8] 孔珑. 工程流体力学[M]. 北京：中国电力出版社，2007. [9] 阎昌琪. 汽液两相流[M]. 哈尔滨：哈尔滨工程大学出版社，2010. [10] PATANKAR S V. Numerical heat transfer and fluid flow[M]. New York: Hemisphere Publishing Corp., 1980. [11] 孙锋，夏国清，孙佳丽. 新型直流蒸汽发生器的动态特性仿真研究[J]. 应用科技，2005，32(8)：49-52.SUN Feng, XIA Guoqing, SUN Jiali. Simulation research on dynamic characteristic of new once-through steam generator[J]. Applied Science and Technology, 2005, 32(8): 49-52(in Chinese). [12] GEAR W C. 常微分方程初值问题的数值解法[M]. 费景高，译. 北京：科学出版社，1987.
