FeCr合金中Cr含量对微观结构影响的原子尺度模拟研究

贾丽霞; 贺新福; 王东杰; 吴石; 豆艳坤; 杨文

doi:10.7538/yzk.2017.youxian.0544

FeCr合金中Cr含量对微观结构影响的原子尺度模拟研究

中国原子能科学研究院反应堆工程技术研究部,北京102413

计量
- 文章访问数: 204
- HTML全文浏览量: 0
- PDF下载量: 1188
出版历程
- 刊出日期: 2018-06-19

Atomic Scale Simulation Research for Effect of Cr Content on Microstructure in FeCr Alloy

Reactor Engineering Technology Research Division, China Institute of Atomic Energy, Beijing 102413, China

摘要

摘要: 低温辐照脆化是影响铁素体/马氏体（F/M）钢服役的主要问题之一。F/M钢低温辐照脆化的主要机理是辐照产生的纳米缺陷（如位错环、α′相(富Cr团簇)等）阻碍位错运动。本文利用分子动力学方法和迈氏蒙特卡罗方法对F/M钢模型材料——FeCr合金（Fe7%Cr、Fe9%Cr、Fe14%Cr）中Cr元素析出成团簇及在位错环上偏析的机理进行研究，并分析Cr团簇析出与合金成分的关系以及位错环尺寸、位错环类型和合金中Cr含量对位错环上Cr偏析量的影响。模拟结果表明：热力学模拟后，高Cr含量（>9%)的FeCr合金中会析出Cr团簇，且基体内Cr含量越高，析出的Cr团簇尺寸越大；在所研究的3种FeCr合金中，受位错环张应力场作用，合金元素Cr均会在位错环的外围偏析，且FeCr合金中Cr含量越高，Cr在位错环上偏析量越高。低Cr的FeCr合金中Cr对其辐照硬化的影响需考虑位错环上Cr偏析的影响，高Cr的FeCr合金中Cr元素对其辐照硬化的影响需综合考虑Cr团簇及位错环上Cr偏析。
- FeCr合金 ,
- 位错环 ,
- Cr团簇 ,
- 应力场 ,
- Cr偏析
Abstract: Lower temperature irradiation embrittlement is one primary issue limiting the use of ferritic/martensitic steels. The primary mechanism of lower temperature irradiation embrittlement is the obstruction of dislocation motion by nano-metric defects, such as dislocation loop and α′ precipitate (Cr clusters), induced by irradiation. Using molecular dynamics and Metropolis Monte Carlo (MMC), the mechanism of Cr precipitate and segregation on dislocation loop in FeCr alloys (the models of F/M steels) was studied. On this basis, the dependence of Cr clusters on Cr contents, and the impacts of loop size, loop type and Cr contents in FeCr alloys on the Cr enrichment on loop were explored. The results show that after simulation, Cr clusters were formed in FeCr alloys with higher Cr contents (>9%) and the size of Cr clusters increases with Cr contents in FeCr alloy. For all the studied FeCr alloys here, under the interaction of tensile stress fields, Cr elements can segregate on the outside of dislocation loop after thermodynamics simulation, and enrichment level of Cr on loop increases with the Cr contents in FeCr alloys. For lower Cr contents, the effect of Cr on hardening only needs to consider the Cr segregation on loops, while for higher Cr contents, the influence of Cr contents on the irradiation hardening needs the synthetical study of Cr clusters and Cr segregation on loops.
- FeCr alloy ,
- dislocation loop ,
- Cr cluster ,
- stress field ,
- Cr segregation

HTML全文

参考文献(26)

[1]	LECHTENBER T. Irradiation effects in ferritic steels[J]. Journal of Nuclear Materials, 1985, 133-134: 149-155.
[2]	KOYAMA A, HISHINUMA A, GELLES D S, et al. Low-activation ferritic and martensitic steels for fusion application[J]. Journal of Nuclear Materials, 1996, 233-237: 138-147.
[3]	CHEN W Y, MIAO Y, GAN J, et al. Neutron irradiation effects in Fe and Fe-Cr at 300 ℃[J]. Acta Materialia, 2016, 111: 407-416.
[4]	BACHHAV M, ODETTE G R, MARQUIS E A. α′ precipitation in neutron-irradiated Fe-Cr alloys[J]. Scripta Materialia, 2014, 74: 48-51.
[5]	CHEN W Y, MIAO Y, WU Y, et al. Atom probe study of irradiation-enhanced α′ precipitation in neutron-irradiated Fe-Cr model alloys[J]. Journal of Nuclear Materials, 2015, 462: 242-249.
[6]	MATHON M H, de CARLAN Y, GEOFFROY G, et al. A SANS investigation of the irradiation enhanced α-α′ phases separation in 7-12Cr martensitic steels[J]. Journal of Nuclear Materials, 2003, 312(2): 236-248.
[7]	POROLLO S I, DVORIASHIN A M, VOROBYEV A N, et al. The microstructure and tensile properties of Fe-Cr alloys after neutron irradiation at 400 ℃ to 5.5-7.1 dpa[J]. Journal of Nuclear Materials, 1998, 256(2): 247-253.
[8]	XU S, YAO Z, JENKINS M L. TEM characterisation of heavy-ion irradiation damage in FeCr alloys[J]. Journal of Nuclear Materials, 2009, 386: 161-164.
[9]	ARAKAWA K, HATANAKA M, MORI H, et al. Effects of chromium on the one-dimensional motion of interstitial-type dislocation loops in iron[J]. Journal of Nuclear Materials, 2004, 329-333: 1194-1198.
[10]	CHEN W Y. Irradiation damage in neutron-irradiated Fe-Cr model alloys[D]. University of Illinois at Urbana-Champaign, 2015. http:∥hdl.handle.net/2142/72981.
[11]	TERENTYEV D, BERGNER F, OSETSKY Y. Cr segregation on dislocation loops enhances hardening in ferritic Fe-Cr alloys[J]. Acta Materialia, 2013, 61(5): 1444-1453.
[12]	ALLEN M P, TILDESLEY D J. Computer simulation of liquids[M]. Oxford: Clarendon Press, 1987.
[13]	OSETSKY Y N, BACON D J. An atomic-level model for studying the dynamics of edge dislocations in metals[J]. Modelling and Simulation in Materials Science and Engineering, 2003, 11(4): 427-435.
[14]	BACON D J, OSETSKY Y N, RONG Z. Computer simulation of reactions between an edge dislocation and glissile self-interstitial clusters in iron[J]. Philosophical Magazine, 2006, 86(25-26): 3921-3936.
[15]	RONG Z, OSETSKY Y N, BACON D J. A model for the dynamics of loop drag by a gliding dislocation[J]. Philosophical Magazine, 2005, 85(14): 1473-1493.
[16]	PLIMPTON S. Fast parallel algorithms for short-range molecular dynamics[J]. Journal of Computational Physics, 1995, 117(1): 1-19.
[17]	OLSSON P, WALLENIUS J, DOMAIN C, et al. Erratum: Two-band modeling of α-prime phase formation in Fe-Cr[J]. Physical Review B, 2006, 74(22): 229906.
[18]	MILLER M K. Atom probe tomography: Analysis at the atomic level[M]. [S. l.]: Springer Science & Business Media, 2012: 158.
[19]	GAO N, WEI K F, ZHANG S X, et al. The energy state and phase transition of Cu clusters in bcc-Fe studied by a molecular dynamics simulation[J]. Chinese Physics Letters, 2012, 29(9): 096102.
[20]	BERGNER F, ULBRICHT A, HEINTZE C. Estimation of the solubility limit of Cr in Fe at 300 ℃ from small-angle neutron scattering in neutron-irradiated Fe-Cr alloys[J]. Scripta Materialia, 2009, 61(11): 1060-1063.
[21]	NOVY S, PAREIGE P, PAREIGE C. Atomic scale analysis and phase separation understanding in a thermally aged Fe-20at.% Cr alloy[J]. Journal of Nuclear Materials, 2009, 384(2): 96-102.
[22]	CHEN W Y, MIAO Y, WU Y, et al. Atom probe study of irradiation-enhanced α′ precipitation in neutron-irradiated Fe-Cr model alloys[J]. Journal of Nuclear Materials, 2015, 462: 242-249.
[23]	HULL D, BACON D J. Introduction to dislocations[M]. [S. l.]: Elsevier, 2011.
[24]	ZHANG Y, MILLETT P C, TONKS M R, et al. Preferential Cu precipitation at extended defects in bcc Fe: An atomistic study[J]. Computational Materials Science, 2015, 101: 181-188.
[25]	BACHHAV M, YAO L, ODETTE G R, et al. Microstructural changes in a neutron-irradiated Fe-6at.% Cr alloy[J]. Journal of Nuclear Materials, 2014, 453(1): 334-339.
[26]	TERENTYEV D, BAKAEV A. Radiation induced strengthening and absorption of dislocation loops in ferritic Fe-Cr alloys: The role of Cr segregation[J]. Journal of Physics: Condensed Matter, 2013, 25(26): 265702.
