基于实验与模拟相结合的气体样品(n,α)反应截面测量方法研究

胡益伟; 崔增琪; 刘杰; 白浩帆; 夏聪; 江浩雨; 陈金象; 张国辉

doi:10.7538/yzk.2022.youxian.0110

基于实验与模拟相结合的气体样品(n,α)反应截面测量方法研究

北京大学物理学院重离子物理研究所核物理与核技术国家重点实验室,北京100871

计量
- 文章访问数: 176
- HTML全文浏览量: 0
- PDF下载量: 229
出版历程
- 刊出日期: 2022-05-19

Cross Section Measurement Method for (n,α) Reaction of Gas Sample Based on Combination of Experiment and Simulation

State Key Laboratory of Nuclear Physics and Technology, Institute of Heavy Ion Physics, School of Physics, Peking University, Beijing 100871, China

摘要

摘要: 建立了一套利用屏栅电离室测量快中子诱发气体样品(n,α)反应截面的方法。针对气体样品测量中存在的样品核数确定、中子注量测量、待测事件挑选等问题，本方法首先利用模拟计算结果选择合适的气体样品有效区域，使得事件区尽量无本底覆盖且易于统计；再利用中子准直器和阴极、阳极信号时间信息，分离并统计样品有效区域产生的事件数；最后利用实验测量的238U(n,f)裂变计数和SuperMC模拟结果，得到有效区域内的中子注量。利用该方法在中子能量为4.71、4.87、5.00、5.12、5.29和5.45 MeV的能点系统地测量了14N(n,α0)反应的相对截面，结果与ENDF/BⅧ.0符合良好。
- (n,α)反应 ,
- 屏栅电离室 ,
- 共振截面 ,
- 气体样品
Abstract: A method for measuring (n,α) reaction cross sections of the gas sample induced by fast neutrons using a gridded ionization chamber (GIC) was established. There are several advantages using the GIC to measure gas samples. With this method, the (n,α) reaction cross sections of inert gases which are hard to exist as a solid can be measured. And the (n,α) reaction cross section for α particle emitting in all directions can be directly measured by using the gas sample. Furthermore, compared with using solid samples, using gas samples have far more nuclei in the measurement samples. Therefore, it is feasible to use neutron source with a better energy resolution to measure the resonance cross sections with gas sample. However, there are many problems to be solved when measuring (n,α) reaction cross section of gas sample by using the GIC. On the one hand, the nuclear reaction event will be affected by the wall effect, when the nuclear reaction is generated near the electrodes of the GIC or at the edge of the electric field. The wall effect will cause the measured event to locate outside the event area which cannot be counted. Not only is the number of nuclei of the gas samples involved in the (n,α) reaction difficult to determine, but the number of events, which are affected by the background or located below the threshold, is also difficult to count. On the other hand, the neutron fluence involved in the measurement of (n,α) reaction cross section of gas sample is difficult to measure. Aiming at solving the problems of the determination of the sample nuclei number, the measurement of neutron fluence, and the selection of events, which are all difficult for the gas sample, this method included three steps: First, simulation calculation was performed to select a suitable effective volume of the gas samples, so that the event is free of background and easy to be counted. Second, the neutron collimator and the timing information of cathode and anode signals were used to select and count the events generated in the effective volume of the gas sample. Third, combining the fission fragment measurement of the 238U(n,f) reaction and the simulation based on SuperMC, the neutron fluence through the effective volume was obtained. Measurements of relative cross sections of the 14N(n,α0) reaction using gas sample were performed at En=4.71, 4.87, 5.00, 5.12, 5.29, and 5.45 MeV. The results are in good agreement with those of ENDF/BⅧ.0 which verified the present measurement method.
- (n,α) reaction ,
- gridded ionization chamber ,
- resonance cross section ,
- gas sample

HTML全文

参考文献(28)

[1]	RAFLIS H, MUHAMMAD I, SU′UD Z, et al. Reflector materials selection for core design of modular gas-cooled fast reactor using OpenMC code[J]. International Journal of Energy Research, 2021, 45(8): 12071-12085.
[2]	杨茂春. 大亚湾核电站一次惰性气体泄漏的监测与分析[J]. 辐射防护，1999，19(5):386-391. YANG Maochun. A case of noble gas leak age searching and analysis in dayabay NPP[J]. Radialization Protection, 1999, 19(5): 386-391(in Chinese).
[3]	SANAMI T, BABA M, SAITO K, et al. (n,α) crosssection measurement using a gaseous sample and a gridded ionization chamber[J]. Nuclear Instruments and Methods in Physics Research A, 2000, 440(2): 403-408.
[4]	SANAMI T, BABA M, SAITO K, et al. (n,α) cross section measurement of light nuclei using gridded ionization chamber and gaseous sample[R]. Tokyo, Japan: Japan Atomic Energy Research Institute, 1998: 192-197.
[5]	BABA M, TAKADA M, IWASAKI T, et al. Development of monoenergetic neutron calibration fields between 8 keV and 15 MeV[J]. Nuclear Instruments and Methods in Physics Research A, 1996, 376(1): 115-123.
[6]	KHRYACHKOV V A, KUZ’MINOV B D, DUNAEV M V, et al. Measurement of the cross sections of the reactions 14N(n,α)11B and 14N(n, t)12C at neutron energies 5.45-7.2 MeV[J]. Atomic Energy, 2006, 101(4): 760-765.
[7]	KHRYACHKOV V A, BONDARENKO I P, KUZMINOV B D, et al. (n,α) reactions cross section research at IPPE[J]. EPJ Web of Conferences, 2012, 21: 03005.
[8]	KHRYACHKOV V A, BONDARENKO I P, KUZMINOV B D, et al. Measurement of the cross section for the reaction 20Ne(n,α)17O in the neutronenergy between 4 and 7 MeV[J]. Physics of Atomic Nuclei, 2012, 75(4): 404-410.
[9]	BONDARENKO I P, KHRYACHKOV V A, IVANOVA T A, et al. Investigation of the 19F(n,α)16N reaction excitation function in neutron energy range of 4-7.35 MeV[J]. Bulletin of the Russian Academy of Sciences: Physics, 2013, 77(4): 459-461.
[10]	JIANG H, CUI Z, HU Y, et al. Crosssection measurements for 58,60,61Ni(n,α)55,57,58Fe reactions in the 4.50-5.50 MeV neutron energy region[J]. Chinese Physics C, 2020, 44(11): 114102.
[11]	HU Y, JIANG H, CUI Z, et al. Simulation method for measurement of the crosssection of the 14N(n,α)11B reaction using a gridded ionization chamber[J]. Nuclear Science and Techniques, 2021, 32(8): 1-11.
[12]	EXFOR. Experimental nuclear reaction data[EB/OL]. [20201101]. https:∥wwwnds.iaea.org/exfor/exfor.htm.
[13]	BAI H, WANG Z, ZHANG L, et al. Simulation of the neutron response matrix of an EJ309 liquid scintillator[J]. Nuclear Instruments and Methods in Physics Research A, 2018, 886: 109-118.
[14]	BAI H, JIANG H, LU Y, et al. Determination of the number of 238U target nuclei and simulation of the neutron induced fission fragment energy spectrum[J]. Applied Radiation and Isotopes, 2019, 152: 180-187.
[15]	WU Y, XIE Z, FISCHER U, et al. A discrete ordinates nodal method for onedimensional neutron transport calculation in curvilinear geometries[J]. Nuclear Science and Engineering, 1999, 133(3): 350-357.
[16]	WU Y. CADbased interface programs for fusion neutron transport simulation[J]. Fusion Engineering and Design, 2009, 84(7): 1987-1992.
[17]	WU Y, SONG J, ZHENG H, et al. CADbased Monte Carlo program for integrated simulation of nuclear system SuperMC[J]. Annals of Nuclear Energy, 2015, 82: 161-168.
[18]	MANCˇIC＇ A, FUCHS J, ANTICI P, et al. Absolute calibration of photostimulable image plate detectors used as (0.5-20 MeV) highenergy proton detectors[J]. Review of Scientific Instruments, 2008, 79(7): 073301.
[19]	SHIMADA K, NAKANII N, MURATA I, et al. Measurement of fast neutron by using imaging plate[J]. Journal of Physics: Conference series, 2010, 244(3): 032059.
[20]	ZIEGLER J F. SRIM2013[EB/OL]. [20201101]. http:∥www.srim.org/#SRIM.
[21]	Matlab[EB/OL]. [20201101]. https:∥www.mathworks.cn/products/matlab.html.
[22]	KONING A, HILAIRE S, GORIELY S, et al. TALYS1.95： A nuclear reaction program user manual[EB/OL]. [2020-11-01]. http:∥www.talys.eu/.
[23]	LIU J, JIANG H, CUI Z, et al. The impacts of the ballistic deficit and electron attachment on the pulse shapes of the Frischgrid ionization chamber[J]. Nuclear Instruments and Methods in Physics Research A, 2021, 1014: 165751.
[24]	CARLSON A D, PRONYAEV V G, CAPOTE R, et al. Evaluation of the neutron data standards[J]. Nuclear Data Sheets, 2018, 148: 143-188.
[25]	江浩雨. 4.50~10.50 MeV能区快中子诱发58,60,61Ni(n,α)55,57,58Fe反应实验研究[D]. 北京：北京大学，2021.
[26]	GABBARD F, BICHSEL H, BONNER T W. The disintegration of nitrogen by fast neutrons[J]. Nuclear Physics, 1959, 14(2): 277-294.
[27]	MORGAN G L. Cross sections for the 14N(n,p0), (n,α0), and (n,α1) reactions from 0.5 to 15 MeV[J]. Nuclear Science and Engineering, 1979, 70(2): 163-176.
[28]	SCOBEL W, FINK R W, BORMANN M. The reactions N14(n,α)B11 and N14(n, t)C12 observed with a gridded ionization chamber[J]. Zeitschrift für Physik, 1966, 197(2): 124-135.
